Промышленное оборудование LBC611-06AB. Точное назначение и характеристики не указаны.
| Part no.: | 1120348 |
|---|---|
| Technology | 2D snapshot |
| Internal lighting | LED, visible blue light, 470 nm, ± 15 nm |
| Feedback spot | LED, visible green light, 525 nm, ± 15 nm |
| Adjustment aid | Laser, visible red light, 630 nm, ± 15 nm |
| Laser class | 1, complies with 21 CFR 1040.10 except for the conformance according to “Laser Notice No. 56” from May 8, 2019 (IEC 60825-1:2014, EN 60825-1:2014) |
| Focus | Adjustable focus (manually) |
| Sensor | CMOS matrix sensor, grayscale values, 1.3 Mpixel, 1,280 px, 960 px |
| Spectral range | Approx. 400 nm ... 900 nm |
| Focal length | 6 mm |
| Dimensions, system (L x W x H) | 50 mm x 40.3 mm x 29.6 mm |
| Enclosure rating | IP54 (EN 60529, EN 60529/A2) |
| Protection class | III |
| Power consumption | Typ. 3.5 W |
| Housing material | Aluminum die cast |
| Output current | ≤ 100 mA |
| Connections | 1 x M12, 17-pin male connector (serial, I/Os, voltage supply)1 x M12, 4-pin female connector (Ethernet) |
| Supply voltage | 12 V DC ... 24 V DC, ± 15 % |
| Window material | PMMA |
| Weight | 165 g |
| Bar code types | 2/5 IndustrialInterleaved 2 of 5CodabarCode 39Code 93Code 128EAN-8EAN13Pharmacode |
| 2D code types | Data Matrix ECC200QR codeMicro QR codePDF417Aztec |
| OCR/OCV fonts | Universal, industrial, document, DotPrint, pharma, OCR-A, OCR-B, Arabic numbers |
| Optical format | 1/3" |
| Maximum encoder frequency | 300 Hz |
| Ethernet | ✔ , TCP/IP |
| Function | EtherNet/IPUDPPROFINET |
| Data transmission rate | (300 Baud ... 115.2 kBaud) |
| Protocol | FTPHTTP |
| Serial (RS-232)✔Data transmission rate(300 Baud ... 115.2 kBaud) | Serial (RS-232) |
| Serial (RS-232) | ✔ |
| Operator interface | Web server |
| Optical indicators | 6 x status display, 2 x LED alignment aids, 1 x feedback spot |
| Ambient temperature, operation | –20 °C ... +70 °C, permissible relative humidity: 0% ... 90% (non-condensing) |
| Ambient temperature, storage | –20 °C ... +70 °C1) |
| Shock load | EN 60068-2-27:2009-05 |
| Vibration load | EN 60068-2-6:2008-02 |
| Items supplied | InspectorP V2D611P-MMSBE4LabelChecker software |
| EU declaration of conformity | ✔ |
| UK declaration of conformity | ✔ |
| ECLASS 5.1.4 | 27289090 |
| ECLASS 6.0 | 27289090 |
| ECLASS 7.0 | 27289090 |
| ECLASS 8.0 | 27289090 |
| ECLASS 9.0 | 27289090 |
| ECLASS 10.0 | 27289090 |
| ECLASS 11.0 | 27289090 |
| ECLASS 12.0 | 27289090 |
| ECLASS 13.0 | 27289090 |
| ECLASS 14.0 | 27289090 |
| ECLASS 15.0 | 27289090 |
| ETIM 6.0 | EC001820 |
| ETIM 7.0 | EC001820 |
| ETIM 8.0 | EC001820 |
| ETIM 9.0 | EC001820 |
| ETIM 10.0 | EC001820 |
| UNSPSC 091201.0 | 81141500 |
| UNSPSC 100501.0 | 81141500 |
| UNSPSC 111201.0 | 81141500 |
| UNSPSC 120901.0 | 81141500 |
| UNSPSC 131201.0 | 81141500 |
| UNSPSC 140801.0 | 81141500 |
| UNSPSC 151101.0 | 81141500 |
| UNSPSC 160901.0 | 81141500 |
| UNSPSC 171001.0 | 81141500 |
| UNSPSC 180801.0 | 81141500 |
| UNSPSC 190501.0 | 81141500 |
| UNSPSC 200601.0 | 81141500 |
| UNSPSC 210901.0 | 81141500 |
| UNSPSC 220601.0 | 81141500 |
| UNSPSC 230701.0 | 81141500 |
| UNSPSC 240301.0 | 81141500 |
| UNSPSC 250901.0 | 81141500 |
| UNSPSC 260801.0 | 81141500 |
| header | value |
| Unit weight | 0.282 Kilograms |
| Net unit weight | 0.282 Kilograms |
| Unit volume | 1485 Cubic Centimetres (cm³) |
| Country of origin | Germany |
| EAN | 4047084499548 |
Заполните форму — ответим с актуальной ценой и сроком поставки в течение рабочего дня
